It is now extremely easy to dynamically modify a number of items, rows, colums, angles, rotation etc. Associative ARRAY progeCAD can now create Associative Arrays entities editable through the properties panel.the new annotative button in the MTEXT editor.new settings for the in-place background color.new functions to Remove formatting of the selected text.new functions to Paste text without formatting.ROTATE on PASTE and PASTEBLOCK Now you can rotate entities while performing Paste operations for a direct alignment of elements.New POLYGON PROPERTIES Enable a set of new properties in order to better manipulate regularly-shaped polylines (rectangles or polygons).Enhanced options to stretch, rotate or scale polygons. New POLYGON GRIPS Enable to display a new set of grips for rectangles or polygon polylines.Two Tool Palettes for the new Structures library are provided, ready to use (Steel standard, Profiles and Wooden details). Steel: Angle, Channel, Tubing, Pipe, S-W-M-HP Shape, S-M-W Tee Shape.New PARAMETRIC 2D LIBRARY Parametric generation and insertion of mechanical/structural components for construction using a dedicated interface:.Users may get automatically a lot of useful information for execution of maintenance, simply scanning the QR Codes visible in the drawings. QR Codes, also known as mobile barcodes, allow to represent text, URLs, contact information etc. Make text in your drawings scannable from QR Codes using any mobile phone or tablet with a camera. QRCODE Create and insert a QRCODE from any text, URL etc.sldasm assembly files created with SolidWorks. SolidWorks IMPORT progeCAD has added import of new essential file formats.Cycling through overlapping objects makes your selection extremely easier. SELECTION CYCLING The control of selection when you select an object that overlaps other objects.PDF with Append function The Append function allows to add a new sheet to an existing PDF to create multi-page PDFs when printing different views of a drawing or different drawings.PDF2DWG 2.0 The New conversion engine with pages preview and such new options as Batch conversion of all PDFs in a folder, multi-page PDF conversion, dashed lines recognition, plus dozens of other important improvements.
It is fully compatible with AutoCAD.įor more information please visit. ProgeCAD Professional is a 2D and 3D drafting CAD software that provides AutoCAD look and functionality at a low cost.
